Technical Specification:
| Model | GKM65P |
| Engine | WEICHAI 380 HP |
| Gearbox | FAST 7DS220 |
| Front Axle Capacity (t) | 13 |
| Drive Axle Capacity (t) | 25+25 |
| Lifting System | Front Lifting Cylinder |
| Tire | 14.00-24 24PR |
| Standard Bucket Capacity (m³) | 25 |
| Drive Mode | 6×4 |
| Curb Weight (t) | 22 |
| Rated Payload Capacity (t) | 43 |
| Maximum Gross Machine Weight (t) | 65 |
| Overall Dimension (L×W×H) (mm) | 8680×3050×3800 |
| Inner Dimension of Container (L×W×H) (mm) | 5600×2850×1550 |
| Maximum Speed (km/h) | 42 |
| Maximum Gradeability (%) | 40 |
| Minimum Turning Radius (m) | 10 |
| Minimum Ground Clearance (mm) | 365 |
| Braking System | SORL System |
Gallery
Brief Description
SINOMACH as a reliable heavy equipment company in China, is making construction equipment for road construction and foundation engineering with decades of experience, SINOMACH has been a high quality heavy equipment maker in China and provide construction equipment and engineering vehicle with resonable prices.
