Single Drum Vibratory Roller GYD102

Single Drum Vibratory Roller GYD102
  • Hydraulic double drum drive, two-speed range and stepless speed change.
  • Vibratory roller: Hydraulic double drum vibration, electronic controlled delayed starting of vibration, great exciting force with high compacting efficiency;
  • Hydraulic steering, articulated frame with flexible operation.
Download
Consulting Products Information
  • Connective design for two anti-corrosive water tanks with large capacity, electronic control water spraying system, intermittent spraying.
  • Hydraulic service brake, Electronic controlled parking brake, brake release device which can be applied for dragging the machine for short distance.
  • Drive and vibration system are equipped with imported famous brand hydraulic components with reliable performance.
Technical Specification:
Model GYD102
Length×Width×Height(mm) 4350×1900×3050
Operating weight (Kg) 10000
Drum width (mm) 1700
Static linear pressure （N/cm） 230
Vibration frequency (Hz） 40/46
Centrifugal force（KN） 110/65
Forward 0~5.5/0~11
Reverse 0~5.5/0~11
Diesel engine Cummins 4BT3.9-C110
Rated output(KW) 82
VR View
