GYL233 Landfill Compactor

GYL233 Landfill Compactor
Download
Consulting Products Information
Technical Parameters of the Road Roller:
Model GYL233
Operating weight (kg) 23000
Rolling width (mm) 2910
Max. travel speed (km/h) 10
Gradeability (%) 100
Dozer blade dimensions （Width×height）(mm) 1650x3000
Wheelbase (mm) 3350
Ground clearance (mm) 435
Teeth number per wheel (Front/reverse) 50/40
Diesel engine SHANGCHAI SC8D200/SC11CB 255
Rated output power （kw） 147/187
Overall dimensions （Length ×width ×height）（mm） 7355×3000×3600
