GYL263 Landfill Compactor

GYL263 Landfill Compactor
Download
Consulting Products Information
Specifications of GYL263 Landfill Compactor:
Model GYL263
Operating weight (kg) 26000
Rolling width (mm) 3430
Max. travel speed (km/h) 10.9
Gradeability (%) 100
Dozer blade dimensions （Width×height）(mm) 1880×3800
Wheelbase (mm) 3500
Ground clearance (mm) 490
Teeth number per wheel (Front/reverse) 50/40
Diesel engine SHANGCHAI SC11CB 255
Rated output power （kw） 187
Overall dimensions （Length ×width ×height）（mm） 8150×3430×3650
