Features of Backhoe Loader 630:
  • Equipped with reliable genuine Cummins engine
  • 4 forward & 4 reverse synchromesh mechanical shift transmission
  • Combined seal cylinder obtains high seal performance and more reliability
  • Improved loader and backhoe performance
Download
Consulting Products Information
  • CARRARO wet type rear axle with multi-disc brake& CARRARO front axle
  • New-type cab with more space, increases comfort and visibility
  • With 2 wheel driving or 4 wheel driving for option
Specifications of Backhoe Loader 630:
Model 630
Diesel Engine Cummins 4BTA3.9-C110
Cummins B4.5
Front Type 12.5-16NHS-12PR(4WD)/11L-16F3-12PR(2WD)
Reort Type Rear tire size 19.5L-24R4-12PR
Rated Power 82/74kW
Rated Speed 2200rpm
Rated Loading bucket capacity 1m³
Rated load 1700kg
Max.dumping reach 845mm
Max.dumping clearance 2714mm
Max. loading breakout force ＞60kN
Rated digging bucket capacity 0.3m³
Max. digging depth 4405mm
Max. digging force 50±10%kN
Max. digging radius 5481mm
Max. dumping height 3737mm
Hydraulic system 110L
Fuel tank 151L
Transmission 18.5L
