Model | 918H |
Length×Width×Height(mm) | 5880×2060×2820 |
Rated load (Kg) | 2000 |
Rated bucket capacity(m3) | 1.1 |
Operating weight(Kg) | 6000 |
Diesel engine | LUOTUO LR4B3-G92X2A |
Rated output(KW) | 60 |
Transmission case | Jingyi |
Gear positions | 2 forward gear, 2 reverse gear |
Max. drawing force(KN) | 48 |
Max. breakout force(KN) | 60 |
Max. dump clearance(mm) | 2750 |
Dump reach (mm) | 920 |
Wheel base(mm) | 2350 |
Total cycle time (s) | 8.5 |
